Hard Scrap Two Stage Recycling Machine Line

Hard Scrap Two Stage Recycling Machine Line

1.suit for common engineering plastics.
2.double stages ,double filters,fewer impurities.
3.easy operation, uniform plasticizing ,full pellets.

Views: 3,248
Contact Us

Product Details

Model Screw dia(mm) Long dia ratio Output(kg/h) Power(kw) Rotate speed(r/min)
LDD-SJP-80-70 Φ80、Φ70 28:1、10:1 50-100 18.5/7.5 10-75
LDD-SJP-90-85 Φ90、Φ85 28:1、10:1 100-150 22/7.5 10-75
LDD-SJP-100-95 Φ100、Φ95 28:1、10:1 150-200 30/11 10-75
LDD-SJP-110-105 Φ110、Φ105 28:1、10:1 200-250 30/11 10-75
LDD-SJP-120-115 Φ120、Φ115 28:1、10:1 250-300 45/15 10-75
LDD-SJP-130-120 Φ130、Φ120 28:1、10:1 300-350 55/15 10-75
LDD_SJP_140_130 Φ140、Φ130 28:1、10:1 350-400 75/18.5 10-75
LDD_SJP_150_140 Φ150、Φ140 28:1、10:1 400-450 90/22 10-75
LDD_SJP_160_150 Φ160、Φ150 28:1、10:1 450-500 110/30 10-75
LDD_SJP_180_160 Φ180、Φ160 28:1、10:1 500-600 132/37 10-75

Double stage plastic granulation unit is in the single stage granulation machine on the basis of an additional machine, but also added a filtering procedure, for dirty PP PE ABS PC PS PA PPR PET and other materials have a higher purification effect, is the most used in the market, the best sales model.

The machine adopts double-stage design, after double-layer filtration, the production of higher particle purity, more uniform plasticization, fuller particles, fully meet the plastic product manufacturers of waste plastic recycling needs, reduce the production cost of plastic products, improve the economic benefits of enterprises.

Double stage plastic granulator screw using 38Crmoal material, and nitriding treatment, has a very high hardness. Gear box using high strength hard tooth surface reduction gear box, durable, smooth operation. The motor uses international brand Siemens motor, loved by customers at home and abroad. The main and auxiliary machines adopt hydraulic net changer, easy to operate, fast net changer, more convenient for workers' production operation. The model has 10 models to choose from, the output range from 50kg/h to 800kg/h, can provide different choices for each customer's different needs.

Yuyao Lvdao Plastic and Rubber Machinery Co., Ltd is well known Hard Scrap Two Stage Recycling Machine Line manufacturers and industrial Hard Scrap Two Stage Recycling Machine Line suppliers in China. We can make the products following the customers' requirements,like the shape,size,color,logo and other spec details. According to the different characteristics of various plastic materials to develop a batch of new products, maximize to meet the needs of customers.
